The Orbi WiFi system from Netgear has one of the best metrics in speed and coverage performance among the WiFi mesh products in the market right now. Together with Linksys Velop, Eero, Google WiFi, Amplifi etc, these products are categorized as the new generation of WiFi network systems, also called Mesh WiFi.
Orbi also shines in other areas, in addition to pure speed and coverage, such as vast selection of product options, extensive software features, flexible connectivity options and much more.
People looking to buy an Orbi system often get confused about the various models available and have a hard time to decide which product kit is the most suitable for their home or office.
In this article we’ll describe the different models and compare them so that you can get a better idea of what each one offers.
Comparison Table
The table below summarizes some important specs of the most popular Orbi models. In this article we are comparing some other models in addition to the ones below so make sure to read the whole article for more comparisons.
Last update on 2023-03-22 at 21:05 / Affiliate links / Images from Amazon Product Advertising API
Models Notation
First lets start with the notation that Netgear uses to name the various models.
Orbi Kit Models
As you might know already, Orbi systems are usually purchased as kits which have a main Router unit and one or more Satellite units which are connected to the main Router either via WiFi Backhaul (dedicated 5 Ghz backhaul link with 1.7 Gbps data speed or 866Mbps speed depending on model) or via wired Ethernet cable.
The main Router unit must be connected to the ISP modem or router offered by your Internet Service Provider. Therefore, the Router unit has a dedicated wired port labeled as “Internet” or “Wan” for this purpose.
Therefore, people usually buy a kit when starting out and for implementing a whole-home WiFi mesh system.
Netgear names the “Kit” models as RBKxx with the letter K showing that this is a Kit system having one Router and one or more Satellites.
The following are the most popular and best selling models:
- RBK30: 1 router + 1 wall-plug satellite (AC2200 wireless max speed of 2200 Mbps)
- RBK40: 1 router + 1 satellite (AC2200 wireless max speed of 2200 Mbps)
- RBK50: 1 router + 1 satellite (AC3000 wireless max speed of 3000 Mbps) (MOST POPULAR MODEL)
- RBK23: 1 router + 2 satellites (AC2200 wireless max speed of 2200 Mbps) (smaller size units)
- CBK40: 1 router + 1 satellite (AC2200) with built-in Cable Modem
- RBK53: 1 router + 2 satellites (AC3000 wireless max speed of 3000 Mbps) (HIGHEST COVERAGE)
Note:
The CBK40 is a special kit system whereby the router unit includes an embedded Cable Modem (DOCSIS 3.0). This means that if your internet connection is via a cable provider, you can replace the ISP cable modem with CBK40 (only if the ISP allows this).
Here are some more 3-unit kits which have 1 router and 2 satellites (for wider coverage).
- RBK33: 1 router + 2 wall-plug satellites (AC2200 wireless max speed of 2200 Mbps)
- RBK43: 1 router + 2 satellites (AC2200 wireless max speed of 2200 Mbps)
- RBK53S: 1 router + 2 satellites (AC3000 wireless max speed of 3000 Mbps) NEW Model. Same hardware as RBK53 but including also security protection license.
Orbi Individual Models
In addition to purchasing a kit of Orbi units (i.e Router + Satellites) you can also purchase the Router and Satellite units individually for expansion of an existing network.
The individual standalone Router units are named as RBRxx with the letter R showing that this is a Router unit.
The individual Satellite units are named as RBSxx with the letter S showing that this is a Satellite unit.
The individual wall plug-in Satellite units are named as RBWxx with the letter W showing that this is a wall-plug Satellite unit.
- RBR20: 1 standalone Router (AC2200) up to 2000 sq.ft coverage (1 LAN port)
- RBR50: 1 standalone Router (AC3000) up to 2500 sq.ft coverage (3 LAN ports)
- RBW30: 1 individual Add-on wall-plug Satellite unit (AC2200) for extra 1500 sq.ft coverage
- RBS40: 1 individual Add-on Satellite unit (AC2200) for extra 2000 sq.ft coverage
- RBS50: 1 individual Add-on Satellite unit (AC3000) for extra 2500 sq.ft coverage
- RBS50Y: 1 individual Add-on Satellite unit (AC3000) for Outdoor use for extra 2500 sq.ft coverage
Orbi Kits Comparison
Since most people are interested in purchasing a kit model for whole-home wireless coverage, we will compare the most popular kit models below in terms of area coverage, speed, connectivity options etc.
RBK30 Vs RBK40
Area Wireless Coverage
- The RBK30 covers homes up to 3500 sq.ft
- The RBK40 covers homes up to 4000 sq.ft
WiFi Speed
- Both models have max combined WiFi speed of 2200 Mbps (AC2200 wifi models)
Connectivity
- The Satellite of RBK30 is wall-plug and does not include LAN ports.
- The Satellite of RBK40 includes 4xLAN Ethernet ports for wire connections.
- The Router unit of both kit models includes 1xWAN and 3xLAN ports.
RBK30 Vs RBK50
Area Wireless Coverage
- The RBK30 covers homes up to 3500 sq.ft
- The RBK50 covers homes up to 5000 sq.ft
WiFi Speed
- The RBK30 has max combined WiFi speed of 2200 Mbps (AC2200)
- The RBK50 has max combined WiFi speed of 3000 Mbps (AC3000)
Connectivity
- The Satellite of RBK30 is wall-plug and does not include LAN ports.
- The Satellite of RBK50 includes 4xLAN Ethernet ports for wire connections.
- The Router unit of both kit models includes 1xWAN and 3xLAN ports.
RBK40 Vs RBK50
- Eliminate WiFi dead zones and buffering - Whole home Mesh Wifi is a new type of connected system for seamless wireless coverage throughout your home
- Replaces your current router, and works with your modem and internet service. Compatible with major internet service providers including Comcast, Time Warner, and Verizon Fios
- Covers up to 4000 square feet with high performance WiFi - WiFi points work together so you can add more if you need additional coverage
Last update on 2023-03-22 at 21:05 / Affiliate links / Images from Amazon Product Advertising API
- Ultra-performance Mesh WiFi network blankets every inch of your home in super fast and seamless WiFi connectivity - room to room, wall to wall, floor to floor
- Eliminates WiFi dead zones and buffering - 5,000 square feet of consistent coverage - with speeds up to 3Gbps
- The most award-winning Mesh WiFi system on the planet: PC Mag, CNET, Wirecutter, Forbes, SmallNetBuilder
Last update on 2023-03-22 at 19:50 / Affiliate links / Images from Amazon Product Advertising API
Area Wireless Coverage
- The RBK40 covers homes up to 4000 sq.ft
- The RBK50 covers homes up to 5000 sq.ft
WiFi Speed
- The RBK40 has max combined WiFi speed of 2200 Mbps (AC2200) and the backhaul band is 866 Mbps (the link connecting satellites with main router).
- The RBK50 has max combined WiFi speed of 3000 Mbps (AC3000) and the backhaul band is 1733 Mbps (the link connecting satellites with main router).
Connectivity
- The Satellites of both RBK40 and RBK50 include 4xLAN Ethernet ports.
- The Router unit of both kit models includes 1xWAN and 3xLAN ports.
Our Recommendation
- If your Internet connection is lower than 150Mbps and also you don’t have much internal home network traffic (i.e sharing files within your home, streaming video within the home network etc) then go with RBK40 model.
- If your Internet connection is more than 150Mbps and you also have some heavy internal traffic requirements (sharing files, streaming etc) then we suggest you to go with RBK50 model.
RBK23 Vs RBK50
The RBK23 is a newer and more economical model launched by Netgear to cover the needs of medium to large sized houses and with some reductions in hardware to lower the price.
The main hardware differences of the RBK23 compared to RBK50 (which is the best selling kit) are the following:
- Smaller size: (5.6 x 2.4 x 6.6 in) compared to (6.4 x 3.1 x 8.0 in).
- Fewer Internal Antennas: The RBK23 has 4 internal antennas compared to 6 antennas of RBK50.
- Fewer Wired Ethernet Ports: The RBK23 has 2 Ethernet Ports while the RBK50 has 4.
- Wireless Backhaul speed: The RBK23 has 866Mbps backhaul speed compared to 1733Mbps of the RBK50
Other than the above hardware differences, the main features of the RBK50 are also supported by RBK23 as well (such as Tri-band WiFi, wireless backhaul on 5Ghz band, beamforming, excellent speed performance and coverage etc).
So if you want to save some money and you don’t care much about the reduced hardware specs, then the RBK23 is a value for money product.
- Tri-band backhaul a dedicated band between your Orbi router and satellite frees up the other two bands for maximum speed to your devices
- Works with all internet providers replace your existing wi-fi router and extender separate modem or gateway required compatible with any internet provider including cable satellite fiber DSL and more
- Wired Ethernet port & fast wireless speed 1 Gigabit Ethernet port and AC2200 Wi-Fi powers up to 22 Gbps of streaming HD video gaming or Internet surfing and downloads
Last update on 2023-03-22 at 21:05 / Affiliate links / Images from Amazon Product Advertising API
Let’s see the rest of the main specs comparison below:
Area Wireless Coverage
- The RBK23 covers homes up to 6000 sq.ft
- The RBK50 covers homes up to 5000 sq.ft
WiFi Speed
- The RBK23 has max combined WiFi speed of 2200 Mbps (AC2200) and the backhaul band is 866 Mbps (the link connecting satellites with main router).
- The RBK50 has max combined WiFi speed of 3000 Mbps (AC3000) and the backhaul band is 1733 Mbps (the link connecting satellites with main router).
Connectivity
- The Router and Satellites of RBK23 include 2xLAN Ethernet ports (on Router there is 1WAN and 1LAN).
- The Router and Satellites of RBK50 include 4xLAN Ethernet ports (on Router there is 1WAN and 3LAN).
RBK33 Vs RBK50
The RBK33 kit contains one main Router wifi device and two wall-plug satellite units. All of the devices work with AC2200 wireless speed which means they support a maximum of 2200 Mbps theoretical combined speed on the wifi network.
- NO MORE DEAD ZONES: Whole home mesh WiFi coverage of up to 5,000 sq. ft. and 20 devices. Mesh technology helps you stay connected as you roam around your home using a single network name. Extend coverage up to 1,500 sq. ft. with additional satellites (sold separately).
- TRI-BAND BACKHAUL: A dedicated band between your Orbi router and satellite frees up the other two bands for maximum speed to your devices
- VERSATILE WALL PLUGS: Two versatile wall plug satellites make placement easy and inconspicuous allowing you to create seamless roaming and strong WiFi connection from room to room.
Last update on 2023-03-22 at 21:05 / Affiliate links / Images from Amazon Product Advertising API
Although the RBK33 has a total of 3 wifi units compared to RBK50 (which has 2 units), the main limitation of the RBK33 is that the satellites are wall-plug units. This has two main disadvantages in my opinion:
- Wall-plug satellite units do not have LAN Ethernet wired ports.
- Wall-plug units don’t offer much flexibility regarding the location to place them in the house since they must be plugged on a power outlet. Usually power outlets are hidden behind furniture and are located lower on the wall. This might limit the area coverage of the system.
On the other hand, the wall-plug satellites of the RBK33 are slim profile and much smaller compared to RBK50. You just plug them on a power outlet for easy expansion of the mesh network.
Area Wireless Coverage
- The RBK33 covers homes up to 5000 sq.ft
- The RBK50 covers homes up to 5000 sq.ft
WiFi Speed
- The RBK33 has max combined WiFi speed of 2200 Mbps (AC2200) and the backhaul band is 866 Mbps (the link connecting satellites with main router).
- The RBK50 has max combined WiFi speed of 3000 Mbps (AC3000) and the backhaul band is 1733 Mbps (the link connecting satellites with main router).
Connectivity
- The Router of RBK33 includes 3xLAN wired Ethernet ports plus 1WAN Ethernet port for connecting to a cable or DSL modem. The satellite units do not include LAN ports.
- The Router and Satellite of RBK50 include 4xLAN Ethernet ports (on Router there is 1WAN and 3LAN) for a total of 7 wired Gigabit ports for connecting devices.
RBK50 Vs RBK53
RBK53 is currently the biggest and most powerful Orbi kit you can buy. RBK53 is basically the same hardware as RBK50 but it has 1 router + 2 satellites instead of 1 router + 1 satellite of the RBK50.
Therefore, the RBK53 will have the same stellar performance as the RBK50 but with much larger house area coverage. It is designed for very large houses with thick walls (up to 7500 sq ft areas, more than 2 floors etc) but its more expensive than the RBK50 model.
Ofcourse you can buy an RBK50 for now and add an extra satellite later on if you still need to cover a bigger area. However, the cost of buying the 50 model and then buying an extra satellite later on will be higher instead of buying the 53 model kit.
- Ultra-performance Mesh WiFi network blankets every inch of your home in super-fast and seamless WiFi connectivity room to room, wall to wall, floor to floor
- Eliminates WiFi dead zones and buffering 7,500 square feet of consistent coverage with speeds up to 3.0 Gbps
- Maintains speed even as more devices use your WiFi at the same time, thanks to patented Tri-band technology. 4 LAN Gigabit Ethernet ports on satellites and router
Last update on 2023-03-22 at 21:05 / Affiliate links / Images from Amazon Product Advertising API
Area Wireless Coverage
- The RBK53 covers homes up to 7500 sq.ft
- The RBK50 covers homes up to 5000 sq.ft
WiFi Speed
- The RBK53 has max combined WiFi speed of 3000 Mbps (AC3000) and the backhaul band is 1733 Mbps (the link connecting satellites with main router).
- The RBK50 has exactly the same wireless characteristics as the above.
Connectivity
- RBK53 has lots of wired ports (4 LAN ports on each satellite and 3 LAN ports on router) with a total of 11 Gigabit wired ports.
- The Router and Satellite of RBK50 include 4xLAN Ethernet ports (on Router there is 1WAN and 3LAN) for a total of 7 wired Gigabit ports for connecting devices.
RBK53 Vs RBK53S
The specs of RBK53 are shown on the section above. The RBK53S is a newer addition to the family and has exactly the same hardware and WiFi specs as the RBK53.
- Includes a free 1-year subscription for NETGEAR Armor with Bitdefender Total Security 2019 ($70 value) - award-winning antivirus, data theft, and cyberattack protection for ALL of your smartphones and computers.
- Maximize range and WiFi speeds with Orbi Whole Home Mesh WiFi System — covers up to 7,500 square feet with speeds up to 2x faster than Google Home. System includes a WiFi router and two satellites.
- That old router you have may be slowing you down. Orbi Mesh WiFi Systems give you the fastest, most secure, and most consistent Internet speeds available, even as more devices connect.
Last update on 2023-03-22 at 21:05 / Affiliate links / Images from Amazon Product Advertising API
The only difference is that the 53S model includes a free 1-year subscription to NETGEAR Armor which is based on Bitdefender Total Security antivirus engine for AV and cyberattack protection. The license covers all of your home devices (smartphones and computers) no matter how many you have.
Keep in mind though that after the first free year, you will need to pay for renewal of NETGEAR Armor which is around $70.
Orbi AC2200 Vs AC3000 Description
I have written an article in the past explaining the meaning of the “AC” specification in the new IEEE 802.11ac standard.
As explained in the article above, the number after the AC spec (AC2200 or AC3000) represents the combined maximum speed of all wireless frequency bands of the device.
In summary:
AC2200: This has 3 frequency bands (1 band at 2.4 Ghz and 2 bands at 5Ghz). The max wifi speed supported on the 2.4 Ghz band is 400Mbps and the max wifi speed supported on the 5 Ghz bands is 866Mbps (thus combined data speed is 400+866+866 = around 2200 Mbps).
AC3000: This also has 3 frequency bands (1 band at 2.4 Ghz and 2 bands at 5Ghz). The max wifi speed supported on the 2.4 Ghz band is 400Mbps and the max wifi speed supported on the 5 Ghz bands is 866Mbps and 1733Mbps (thus combined data speed is 400+866+1733 = 3000 Mbps).
Does Orbi AC2200 models work with AC3000 models?
I get a lot of question about mixing up various Orbi models and specifically mixing AC2200 with AC3000 models. The short answer is that you CAN mix models together with no problem. The only issue is that if you mix an AC2200 unit with an AC3000 unit, the whole system will drop to AC2200 max speed.
For example, assume you have an RBR50 router which is AC3000. You can buy an RBW30 wall-plug satellite (which is AC2200) and connect it to the RBR50. However, the entire network will drop to AC2200.
